Attention：
The wire displacement sensor is a precision instrument. It is strictly prohibited to knock, hit or collide during installation. Improper installation and use will affect the performance and service life of the sensor. The magnetic bottom balance block should be installed firmly, and the slider should be strong under the magnetic action. The operation should be stable, prevent the slider from coming off, and directly recover.
There are two screw fixing holes at the bottom. And this makes it can directly install or add other accessories according to the needs of the site and the installation space of the machine. When installing the outlet head, make sure that is vertical to the outlet, that is, try to make the wire rope perpendicular to the outlet, keep it to a minimum angle (≤3°) to ensure measurement accuracy and steel rope life.
The surface of the wire rope should not be subjected to improper cutting, burning, impact etc., otherwise it will affect the life of it, and resulting in uneven surface of the wire and not stable movement of the wire from outlet.
Please not pull the wire rope by hand or other objects and let it bounce back. This will likely cause the wire rope to break and damage the structure of the instrument body.
